SPECIFICATIONS
Physical Characteristics
Dimensions 214 (L) x 148 (W) x 30 (H) mm
Weight 1000g / 35.27 oz. (without antenna)
Material Aluminium alloy
Expansion Slot 1 slot for Nano SIM card, 1 slot for TF card
Input Voltage DC 10V – 24V
Standby Current < 30mA
Comm Interface 1*RS-232 , 1*RJ45, 3*USB2.0 Type A, 1*Type C, USB Host
GPIO 4 Input Optical-couplings, 4 Output Optical-ouplings, isolation
Baud Rate 115200 bps
Cooling Mode Air cooling
Work Current 1300mA +/-5% @ DC 12V Input
Display Interface HDMI Type A, support 720P
Power Supply DC (12V), POE (802.3af 13W), POE+ (802.3at 25.5W)
Communication
Ethernet interface 10/100 Base-T Ethernet (RJ45)
WLAN Support 802.11 a/b/g/n/ac/d/e/h/i/k/r/v,2.4G/5G dual-band, IPV4,IPV6;
Fast roaming: PMKID caching, 802.11r, OKC;
Operating Channels: 2.4G(channel 1~13), 5G(channel 36,40,44,48,52,56,60,64,100,104,108,112,116,120,124,128,132,136,140,149,
153,157,161,165), Depends on local regulations;
Security and Encryption: WEP,WPA/WPA2-PSK(TKIP and AES),WAPI-
PSK—EAP-TTLS,EAP-TLS, PEAP-MSCHAPv2, PEAP-LTS,PEAP-GTC,etc.
WWAN (Europe, Asia) 2G: B1/B5/B8
3G: CDMA EVDO: BC0
TD-SCDMA: B34/B39
WCDMA: B1/B5/B8
4G: TDD-LTE: B34/B38/B39/B40/B41
FDD-LTE: B1/B3/B5/B7/B8/B20
WWAN (America) 3G: B2/B4/B5
4G: B2/B4/B5/B7/B12/B13/B17/B28a/B28b
Bluetooth Bluetooth 4.2/4.1+HS/4.0/3.0+HS/2.1+EDR
Developing Environment
Operating System Android 9.0
SDK Chainway Software Development Kit
Language Java
Tool Eclipse/Android Studio
Performance
CPU Qualcomm 1.8 GHz Octa-core
RAM+ROM 3 GB + 32 GB
2 GB + 16 GB (optional)
User Environment
Operating Temp. -25 °C to 65 °C
Storage Temp. -40 °C to 85 °C
Humidity 10% - 95%
UHF RFID
Engine CM710-4 module based on Impinj E710
Frequency 865-868 MHz / 920-925 MHz / 902-928 MHz
Impinj Gen2X Supported
Protocol EPC global UHF Class 1 Gen 2 / ISO 18000-6C
Antenna Supporting a variety of antennas, such as 6dBic, 9dBic
Output Power 1W (30dBm, support +5~+30dBm adjustable, POE/DC power)
2W Optional (33dBm, support +10~+33dBm adjustable, POE+/DC power, for Latin America, etc.)
Output Power Precision +/- 1dB
Output Power Flatness +/- 0.2dB
Receive Sensitivity < -84dBm
RSSI Supported
Ambient Temp Monitor Supported
Fastest Read Rate 900+ tags/sec
Antenna Detector Supported
Antenna Port 4 channel 50Ω TNC port
