ZYPOS INTELLIGENT SYSTEM CO., LTD.

      Print Method

      Thermal line printing

      Interface Type

      USB / USB+LAN / USB+LAN+RS232（optional）

      Style

      Black And White

      Max Paper Size

       80mm

       Max. Resolution

       576 dots/line

       Specifications

  Interfaces USB/Serial/Parallel/Ethernet/Wifi/Bluetooth(Optional)

  Print Comand ESC/POS

  Print Method Thermal Line Printing

  Print Speed 260mm/sec

  No. of Total Dots 512 dots/Line

  Auto Paper Cutter Full or Partial cut

  Print Width 72±0.5mm

  Character Set Alphanumeric /Chinese Kanji

  Print Font 12 x 24; 24x 24

  NV Flash 256K bytes

  Compatible OS Window Systems ; Android & IOS Operate Systems

  Paper

  Type Roll Paper

  Width 79.5±0.5mm

  Roll Diameter 83mm

  Paper Thickness 0.06-0.08mm

  Electrical

  Adapter Voltage DC24V/2.5A

  Cash Drawer Control 12V/1A

  Print Head Reliability

  Print Reliability 100km

  Physical

  Dimension 18.6*14.5*13.6cm

  Unit Weight 2kgs(with accessories)

  Pieces Per CTN 8 Pieces

  Color Black and White

  CTN Dimension 48 x 46 x 36cm

  Carton Weight 17kgs

  Environmental

  Temperature Working: 0 to 45 Degrees

  Humidity Working: 10%-80%

  Warantty 12 months at least

  Certificates CE& FCC ROHS / ISO9001:2008
